Reach Out Anytime

Give us a call directly at (715) 468-2929. Or, if you prefer, complete the form and we’ll answer your question via email or schedule a time to talk.

Career Resume Form

Typically the review is two phases:

Phase 1
Review and approve the part orientation, datum locations, clamp locations, overall size, and all the other major defining features.

Phase 2
Review the overall design concept, access, functionality, material utilization, and final details for the fixture.

After final design approval, to track changes and ensure good communication throughout the post-design process, an Engineering Change Notification (ECN) is created and submitted for customer approval for any changes in customer parts or models and/or customer-driven changes in scope, cost, or project timelines.

Dimensional Quality / Fit and Finish

Our CMM FaroArms utilize the most recent software to qualify directly off the 3D model for precise, fast data.
Weld fixtures are inspected and shimmed to nominal, and inspection fixtures are typically qualified at 10% of print tolerance. Parts are checked to print tolerances.

Run-off to test function

Performing run-off proves complete functionality of the tooling.
If you need a more involved run-off, we provide a designated area, including a 5-ton crane and privacy curtain.
If changes or modifications are required, we have full, in-house manufacturing support, including machining (CNC milling, lathe, grinding, waterjet, wire EDM, etc.), plumbing, and electrical.

Let’s connect.

Reach out anytime.
